Technical standard:
1.Nominal Pressure:PN≤1.6Mpa
2.Applicable temperature: cold & hot water, gas, oil etc
3.Applicable temperature:-20℃≤T≤150℃
4.Thread standard:55°inch system pipe thread.
DN | SIZE | L | B | H |
15 | 1/2" | 65 | 15 | 90 |
20 | 3/4" | 67 | 19 | 100 |
25 | 1" | 73 | 23 | 105 |
32 | 1¼" | 75 | 25 | 112 |
40 | 1½" | 84 | 30 | 118 |
